Projekt FROG3



Gratis Counter

Download

Detailed description english (PDF 1,1 MB)

FROG3, more than a CW-keyer



      • Paddle and sensor firmware are implemented and switchable in real time.
      • Three signal-outputs Keyer, Dash, Dot
      • The speed is adjustable between < 5 Wpm and HSC
      • Favourite CW-speed stored for retrieval at the low position of the speed potentiometer
      • Direct CW-rate input from 15 to 30 WPM, also direct input on the numpad
      • The 16-Key-Pad allows fast access to all important functions
      • Optical coupling to the TX and GAP algorithm against RF-interference
      • Seven memories with 3x20 and 4x50 characters are accessible via menu and available as macros
      • Six memories 1x50, 4x120, 1x200 characters are accessible by buttons (read / write)
      • Comfortable memory input with straying and repetition of the last word
      • 18 Commands embeddable in memory text
      • Two memory recall modes are  selectable, stack or quick change
      • IAMBIC-modes, no memory, dot-memory, dot- and dash-memory
      • Dash / Dot ratio (weight) dynamically adjustable and
      • Quick change between thumbprint-weight or standard-weight
      • Interactive effect when programming the keyer is achieved by two different pitches
      • Quick straight key emulation by function-key
      • 5-digit counter for contest number assignment
      • 3 contest output formats selectable 109, 1T9, 1TN
      • Adjustable burst with switchover to continuous tone for TX-tuning as function-key
      • Setup and status of FROG-3 available as CW plain text
      • Battery voltage monitoring, warning if < 2.75 V (reference 2 x 1.5 V cells).
      • 30 uA current consumption in sleep mode will protect long operating
      • PCB design available

        •  Shift recorder with 50 characters "CW on the fly" or "what I gave"

      • Detection and storage of the partner calls while typing and available as a macro: K
      • Detection and storage of the partner name during input and available as a macro: L
      • DEL clears the Shift recorder
      • MON outputs the shift recorder content on the speaker
      • FM6 transfers the contents of the shift- recorder to memory 6
      • FCN output the currently stored partner-call and the partner-name to the speaker

        •  Semi-automatic, programmed, fast memory configuration

      • Memory 1-4 Standard QSO operation using macros T, U, V, P
      • Memory 1-4 Standard QSO operation supplementary using the Fly-macros K, L
      • Memory 1-2 DX-operation usage of macro :T
      • Memory 1-3 Contest operation usage of macros T: X, Y

        •  Integrated CW trainer with 9 different exercise programs

      • 1 = 5-letter groups random Training
      • 2 = 5-numbers groups random Training
      • 3 = 5-signs groups random Training
      • 4 = letters + numbers 5-series groups random training
      • 5 = letters + numbers + sign 5-series groups random training
      • 6 = learn letters
      • 7 = learn numbers
      • 8 = learn Standard signs
      • 9 = learn special signs
      • 0 = memory-6 random training from your own text)
